Truth table for the following digital circuit will be :
| X | y | Z |
| 0 | 0 | 1 |
| 0 | 1 | 1 |
| 1 | 0 | 1 |
| 1 | 1 | 1 |
To determine the truth table for the given digital circuit, we need to analyze the logic gates used in the circuit.
The circuit contains:
- An XOR gate, taking inputs X and Y.
- An AND gate, taking the output of the XOR gate and a direct input Y.
The output of the XOR gate is given by the expression:
\(X \oplus Y = (\overline{X} \cdot Y) + (X \cdot \overline{Y})\)
The AND gate output, which is the final output Z, will be:
\(Z = (X \oplus Y) \cdot Y\)
Now, let's fill in the truth table using the above expressions:
| X | Y | Z = ((X ⊕ Y) · Y) |
|---|---|---|
| 0 | 0 | 1 |
| 0 | 1 | 1 |
| 1 | 0 | 1 |
| 1 | 1 | 1 |
The correct truth table is:
| X | Y | Z |
| 0 | 0 | 1 |
| 0 | 1 | 1 |
| 1 | 0 | 1 |
| 1 | 1 | 1 |
This matches the given correct answer.
